30 Ton Twin Beam Upside Down Skid Steer Log Splitter (TB530)

30 Ton Splitting Force • Twin 8" Beams • Universal Skid Steer Mount • Made in the USA

Turn your skid steer into a serious firewood-processing machine with the TB530 30 Ton Twin Beam Upside Down Skid Steer Log Splitter. Designed to attach to a Bobcat or compatible skid loader, this heavy-duty splitter allows you to split logs directly from the operator’s seat while reducing the need to lift large rounds by hand.

The standard TB530 features a 5" x 30" welded hydraulic cylinder with a 30-inch opening, delivering up to 30 tons of splitting force. For customers who split longer firewood or feed larger wood stoves and outdoor boilers, an optional 5" x 36" cylinder upgrade is available.

Built with dual 8-inch heavy-duty beams, this is one of the strongest skid steer log splitter designs available. The twin-beam layout includes a viewing window that lets the operator see between the beams for better visibility and more accurate splitting placement. The splitter can also grip and position logs over a wagon, trailer, or truck bed, helping reduce manual handling and improve productivity.

This American-made splitter includes a universal skid steer mounting plate, hydraulic hoses, and flat-face disconnects.

Key Features & Benefits

• 30 Tons of Splitting Force
  Delivers up to 60,000 lbs. of splitting power for tough firewood-processing jobs.
• Twin 8" Heavy-Duty Beams
  Dual-beam construction provides exceptional strength and durability for demanding use.
• Upside Down Skid Steer Operation
  Allows the operator to split logs from the skid steer seat without repeatedly lifting heavy rounds onto a splitter beam.
• 30" Standard Opening
  Standard model includes a 5" x 30" welded cylinder for handling large logs.
• Optional 36" Cylinder Upgrade
  Upgrade to a 5" x 36" cylinder for longer firewood or larger stove applications.
• Unique Viewing Window
  Twin-beam design allows the operator to see between the beams for better visibility of the log and wedge position.
• Log Gripping and Positioning Capability
  Can help hold and position logs over a wagon, trailer, or truck bed to reduce manual loading.
• Universal Skid Steer Mounting Plate
  Fits compatible skid steers using the universal two-lock-handle quick-attach style mounting system.
• Hydraulic Hoses and Flat-Face Disconnects Included
  Comes ready to connect to compatible skid steer hydraulic systems.
• 12" High Single Wedge
  Heavy-duty wedge is built for splitting large, difficult rounds.
• Optional 4-Way Wedge
  Slip-on 4-way wedge bolts behind the single wedge and can be removed when not needed.
• Made in the USA
  American-built for dependable quality and long-term use.
• Durable Painted Finish
  Splitters are sandblasted, wiped down, and painted black with Diamond Vogel Pinnacle 460 3.5 VOC two-part polyurethane.

Available Options

• 36" Opening Upgrade
  Includes a 5" x 36" cylinder for longer logs and larger firewood applications.
• Optional 4-Way Wedge
  A 22-inch-wide slip-on 4-way wedge that bolts behind the single wedge for faster splitting of suitable logs.

Ideal Applications

The TB530 is well suited for:

• Firewood production
• Farm and ranch use
• Woodlot cleanup
• Tree service work
• Land clearing
• Processing large rounds
• Loading split wood into trailers, wagons, or truck beds
• Skid steer owners who want to reduce manual lifting

Quick Specifications

Specification	Details
Model	TB530
Equipment Type	Upside Down Skid Steer Log Splitter
Splitting Force	30 Tons / 60,000 lbs.
Standard Cylinder	5" x 30" Welded Cylinder
Optional Cylinder	5" x 36" Welded Cylinder
Cylinder Rod	2.5"
Standard Opening	30 in.
Optional Opening	36 in.
Beams	Twin 8" Heavy-Duty Beams
Wedge	Single 12" High Wedge
Optional Wedge	22" Wide 4-Way Wedge
Mounting Plate	Universal Skid Steer Quick Attach
Hoses and Connectors	Included
Color	Black
Standard Length	84 in.
Optional Length	96 in.
Shipping Weight	980 lbs.
Warranty	1-Year Limited
Made in USA	Yes

Shipping and Delivery Information

This log splitter ships by freight truck. The customer is responsible for unloading the crate from the truck.  Some assembly is required.

Important Compatibility Information

Confirm that your skid steer has a compatible universal quick-attach mounting system and the hydraulic flow, pressure, and coupler setup required to operate this attachment. Always follow the manufacturer’s operating and safety instructions when connecting, lifting, transporting, or splitting logs.
